NVR824-128ER-IM-8G

Model

NVR824-128ER-IM-8G

NVR824-256ER-IM-16G

Video/Audio Input

IP Video Input

128-ch

256-ch

Two-way Audio Input

1-ch, RCA

Network

Incoming Bandwidth

768Mbps

Outgoing Bandwidth

768Mbps

Remote Users

128

256

Protocols

TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, NFS

Browser

IE(IE10/11) for Windows
Firefox (version 52.0 and above) for Windows
Chrome(version 45 and above) for Windows
Edge(version 79 and above) for Windows

Video/Audio Output

HDMI/VGA Output

VGA:
1920x1080p/60Hz, 1920x1080p/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz
HDMI1/HDMI2:
4K (3840×2160)/30Hz, 1920x1080p/60Hz, 1920x1080p/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz

Recording Resolution

12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF

Audio Output

1-ch, RCA

Audio Compression

G.711A, G.711U

Synchronous Playback

16-ch

Live View Display

VGA: 1/4/6/8/9/16/25/36
HDMI1, HDMI2: 1/4/6/8/9/16/25/36/64

Corridor Mode Screen

3/4/5/7/9/10/12/16/32

Snapshot

FTP/Schedule/Event Snapshot

128-ch snapshot, up to 4K resolution

Decoding

Decoding format

Ultra 265, H.265, H.264

Live view/Playback

12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF

Capability

3 x 12MP@30, 5 x 4K@30, 20 x 1080P@30, 24 x 1080P@25, 40 x 960P@25, 45 x 720P@30, 54 x 720P@25, 96 x D1

Hard Disk

SATA

24 SATA interfaces

Capacity

Up to 16TB for each HDD
(The maximum HDD capacity varies with environment temperature)

Extension board

4

miniSAS*

2 miniSAS ports

eSATA

1 eSATA interface

Disk Group

Support

Disk Array Type

RAID 0, 1, 5, 6, 10, 50, 60

Smart

VCA Detection by IPC

Face Detection, Face Comparison, Intrusion Detection, Cross Line Detection, Enter Area, Leave Area, Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, Temperature Detection(Fire Detection, Smoking Detection, Temperature Measurement, Smoke and Fire Detection), Ultra Motion Detection(UMD), Video Metadata (Mixed-Traffic Detection), Traffic Monitoring

Smart by NVR

Face Comparison, Smart Intrusion Prevention (SIP), Video Metadata (At same channel, only one smart function by NVR can be enabled simultaneously.)

VCA Search

• Face Snapshot Search, Face Comparison Search, Motor Vehicle Search, Non-Motor Vehicle Search,
• Human Body Search, General Search, Search by Image, People Counting Report

People Counting

People Flow Counting, Crowd Density Monitoring

Smart Intrusion Prevention (SIP), Vehicle Detection, Face Detection, Face Comparison, UMD, Video Metadata by Camera

Total 64-ch

Video Metadata by NVR with normal cameras

64-ch

128-ch

SIP by NVR with normal cameras

64-ch

128-ch

Face Comparison by NVR with normal cameras

64-ch

128-ch

Face Comparison by NVR with face detection cameras

128-ch

256-ch

Video Metadata Attribute

• Motor Vehicle: Vehicle Color, Vehicle Type, Vehicle Brand, Direction.
• Non-Motor Vehicle: Non-Motor Vehicle Type, Direction, Gender, Age, Upper Garment Length.

Human Body: Gender, Age, Mask, Hairstyle, Bag Style, Direction, Upper Garment Length, Lower Garment Length.

Face Picture Library

Up to 128 face picture libraries, with up to 500,000 face pictures in total

Vehicle Picture Library

Up to 5 vehicle picture libraries, with up to 25,000 vehicle pictures in total

External Interface

Network Interface

4 RJ-45 10M/100M/1000M adaptive Ethernet Interface

Serial Interface

1 x RS232, 1 x RS485

USB Interface

Front panel: 2 x USB2.0, Rear panel: 2 x USB3.0

Alarm In

24-ch

Alarm Out

8-ch

Power Output

12V

General

Power Supply

100 ~ 240V AC
Power Consumption: ≤ 300 W (without HDD)

Working Environment

-10°C ~ + 50°C (+14°F ~ +122°F), Humidity ≤ 90% RH (non-condensing)

Dimensions

533mm ×484.6mm × 175.5mm (21.0 “×19.1″ ×6.9”)

Weight (without HDD)

≤ 12.5 Kg (27.56 lb)

Certification

Certification

CE, FCC, UL, RoHS, WEEE

CE

EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035

FCC

Part15 Subpart B
